Description
Detailed Product Description
Model: CNC Engraver CTE8090S
The machine adopt cast iron body, X Y Z adopt line rotundity guide, install on the machine directly, can increase the rigidity of the machine, X Y Z axes is import from overseas about the precision nut pole, running characteristic is good and precision is high. T his machine can engrave precision arts and crafts. Accept the standard HPGL(TM) plot instruction and G code digital processing instruction, and accept with other software, the main axes adopted 700W main axes electricity machine, no noise, no pollution, long life. The electronic parts are designed well.
FEATURES:
1. the configuration is steel, the running is calm. 2. importing high precision running ball three axes transmission, high precision. 3. 32 digit DSP several axes running controlling machine, the precision is 0.005mm .
4. the Japanese motor cooperate the mini-step fractionating driver.
5. importing frequency conversion adjusting machine cooperate with the high-power changing axes.
6. the maximum speed is 9m /second, the engraving speed is 6m /second.
7. standard diameter nip head, you can use any standard engraving blades and milling cutter.
8. Accept the standard HPGL(TM) plot instruction and G code digital processing instruction, and accept with other software, the software are Casmate engraving software, CAXA engraving software, ARTCAM art embossing software, Type3 engraving software, artcut software and Pro-E, Master CAM, UG mold software.
PARAMETERS:
Model: CTE8090S
The size of the working table (mm): 900*1270
XYZ travelmm: 800*900*90
Maximum running speedmmmin: 9000
Maximum engraving speedmmmin: 6000
Precisionmm: 0.05
Repetition location precision: 0.05
Acceptable media widthsmm: 100
Power consumptionw: 150
Main axes/collet: 700W/ Φ6, Φ3.175
Running speed of the main axes(turns): 600-24000
Interface: PCI
Engraving order: HP-GL G-code
Running circumstance: Temperature+ 5~+35,relative humidity30%-75%
Electronic pressure: AC220V±10% 50HZ
Weight (kg): 260
Dimension (mm): 1405×1150×1200
